This IC can be manufactured in three forms and those are in 8 pin SOIC package, 8 pins Dual-in-line package, and in TO5-8 metal can form.
Even it holds the characteristics of protecting the device at the time of short circuit and has internal frequency compensating circuit networks. This operational amplifier can offer a high range of voltage gain and this can be made to function at various voltage levels and this functionality allows the device to implement in various integrators, summating type of amplifiers, and others. IC 741 op-amp is made from various stages of the transistor which commonly have three stages like differential i/p, a push-pull o/p, and an intermediate gain stage. The main function of this IC 741 is to do mathematical operations in various circuits. The current version of the chip is denoted by the famous IC 741 op amp. The triangular form in the IC signifies an op-amp integrated circuit. The most significant pins are 2,3 and 6, where pins 2 and 3 denote inverting & non-inverting terminals, and pin 6 denotes output voltage. The representation of 741 IC op-amp is given below which comprises eight pins. The IC 741 operational amplifier looks like a small chip. You need to know basic information about this.
Various kinds of differential amplifiers include the instrumentation amplifier, the isolation amplifier, the negative feedback amplifier, and the fully differential amplifier. The operational amplifier is one kind of differential amplifier. Operational amplifiers may be packed as apparatuses, or used as fundamentals of more compound integrated circuits. The cost of the several typical op-amps is low in reasonable production volume but some hybrid, integrated op-amps with different performance conditions may cost over 100 dollars. The applications of these ICs include an immense array of industrial, scientific, and consumer devices. Nowadays, operational amplifiers are the most commonly used integrated circuits.
